co-ax 同軸閥MK 10 DR
標稱電壓 Un 24 V DC
Un 230 V 40-60 Hz AC
驅動 DC 直流電磁鐵
AC 內置式整流器的直流電磁鐵
絕緣等級 H 180 °C
防護等級 IP65
負載率 ED 100%
連接 按DIN EN175301-803標準的插頭, 形式A 4個位置X90°, 電線直徑 6-8 mm
M12x1 按DESINA標準的接頭 / VDMA
閥門的設計是基于介質和工況的要求.這些因素可能導致設計、密封材料和特性與通用參數表上的規格有所不同.
特性
端口 螺紋 G 1/4 - G 3/4
功能 NC
壓力范圍 0-40 / 0-100 bar
KV值 0 - 40 bar: 2,2 m3/h
0 - 100 bar:1,4 m3/h
介質 氣態? 液態? 高污染?
流向 見壓力范圍
開關周期 200 1/min
開關時間 打開 135 ms
關閉 20 ms
介質溫度 DC -10 °C — +80 °C
AC -10 °C — +80 °C
環境溫度 DC -10 °C — +80 °C
AC -10 °C — +80 °C
重量 2,5 kg
coax電磁閥
coax氣動閥
coax壓力控制閥
coax插裝閥
coax真空閥
主要型號
coax同軸閥MK10
coax同軸閥MK15/FK15
coax同軸閥MK20/FK20
coax同軸閥MK25/FK25
coax同軸閥MK32/FK32
co-ax MK10
co-ax MK15
co-ax MK20
co-ax MK25
co-ax MK32
co-ax MK40
co-ax MK50
co-ax FK15
co-ax FK20
co-ax FK25
co-ax FK32
co-ax FK40
co-ax FK50
co-ax FK65
co-ax FK80
co-ax MK10DR
co-ax MK15DR
co-ax MK20DR
co-ax MK25DR
co-ax MK32DR
co-ax MK40DR
co-ax MK50DR
co-ax FK15DR
co-ax FK20DR
co-ax FK25DR
co-ax FK32DR
co-ax FK40DR
co-ax FK50DR
co-ax FK65DR
co-ax FK80DR
co-ax CFM08
co-ax MCF08
co-ax VMK10
co-ax VMK15
co-ax VMK20
co-ax VMK25
co-ax VMK32
co-ax VMK40
co-ax VMK50
co-ax VFK15
co-ax VFK20
co-ax VFK25
co-ax VFK32
co-ax VFK40
co-ax VFK50
co-ax VMK10DR
co-ax VMK15DR
co-ax VMK20DR
co-ax VMK25DR
co-ax VMK32DR
co-ax VMK40DR
co-ax VMK50DR
co-ax VFK15DR
co-ax VFK20DR
co-ax VFK25DR
co-ax VFK32DR
co-ax VFK40DR
co-ax VFK50DR
co-ax VSV-M40
co-ax VSV-M50
co-ax VSV-F40
co-ax VSV-F50
co-ax VSV-F65
co-ax VSV-F80
co-ax VSV-F100
co-ax VSV-F125
co-ax VSV-F150
co-ax VSV-F200
co-ax VSV-F250
co-ax VSV-M40DR
co-ax VSV-M50DR
co-ax VSV-F40DR
co-ax VSV-F50DR
co-ax VSV-F65DR
co-ax VSV-F80DR
co-ax VSV-F100DR
co-ax VSV-F125DR
co-ax VSV-F150DR
co-ax FCF-K65
co-ax FCF-K80
co-ax FCF-K100
co-ax FCF-K125
co-ax FCF65
MD
磁性液壓缸ISO 6020/2
符合ISO 6020/2標準的拉桿液壓缸，用于電磁開關。
適用于標準中定義的所有安裝件，根據應用的條件和要求的性能，可以采用幾種密封配置。
ISO 6020/2-DIN 24554，帶拉桿。
產品特點
氣缸
ISO
6020/2 -DIN 24554 孔
從25到125
壓力
最大：160bar
感應器
里德
PNP
選件
ROD
不銹鋼
淬硬鋼
Nikrom組合
板
Conforti CD_SX_25_12_X_V_*_SJ 50_S___
Conforti CD_SX_25_18_A_Z_*_SJ 100_L_SF_SV_SR
Conforti CD_SX_32_14_B_K_*_SJ 150_H_ST_SZ_SH
Conforti CD_SX_32_18_E__*_SJ 200_G_SL_SK_
Conforti CD_SX_32_22_D__*_____
Conforti CD_SX_40_18_C__*_____
Conforti CD_SX_40_22_M__*_____
Conforti CD_SX_40_28_G__*_____
Conforti CD_SX_50_22_H__*_____
Conforti CD_SX_50_28_L__*_____
Conforti CD_SX_50_36_Q__*_____
Conforti CD_SX_63_28_R__*_____
Conforti CD_SX_63_36_S__*_____
Conforti CD_SX_63_45_T__*_____
Conforti CD_SX_80_36___*_____
Conforti CD_SX_80_45___*_____
Conforti CD_SX_80_56___*_____
Conforti CD_SX_100_45___*_____
Conforti CD_SX_100_56___*_____
Conforti CD_SX_100_70___*_____
Conforti CD_SX_125_56___*_____
Conforti CD_SX_125_70___*_____
Conforti CD_SX_125_90___*_____
Conforti CD_SX_160_70___*_____
Conforti CD_SX_160_90___*_____
Conforti CD_SX_160_110___*_____
Conforti CD_SX_200_90___*_____
Conforti CD_SX__110___*_____
Conforti CD_SX__140___*_____
北京漢達森德國本土采購，拼箱發貨報關，德國技術，終身售后服務，貨期保證，價格公道，歡迎垂詢!如需更多信息歡迎垂詢漢達森品牌專員吳亞男。
